The SMP6004 and SMP6005 are RF switch modules designed as star configurations. A star switch allows any channel to be connected to any other channel. This configuration approach also allows for the creation of simple matrices (i.e. 4 x 1 x 4).
For applications that require unswitched signal sources to be terminated into 50 ohm, optional 1/2 watt 50 ohm terminations can be provided. Both modules are configured to avoid any unterminated stub effects, and utilize high bandwidth RF relays.
The SMP6004 and SMP6005 are part of the SMIPII™ family and can be mixed and matched with other SMIPII™ modules to configure high-density switching systems.
For applications that require unswitched signal sources to be terminated into 50 ohm, optional 1/2 watt 50 ohm terminations can be provided. Both modules are configured to avoid any unterminated stub effects, and utilize high bandwidth RF relays.
The SMP6004 and SMP6005 are part of the SMIPII™ family and can be mixed and matched with other SMIPII™ modules to configure high-density switching systems.
